Description
Features:
Bridge Club is for those multi-surface outings — planned or unplanned. We've all run out the clock on a dirt tour and had to add in some paved shortcuts. Conversely, when you’re feeling a little zesty on your next road tour, Bridge Club is ready for reroutes through the woods.
Some people hear "bike touring" and immediately think of long-forgotten stretches of highway, small-town oddities, and roadside attractions. Some instantly recall desolate stretches of desert dirt roads or lush green forest trails. With Bridge Club, you can have your dessert and eat it too!
Ultra-focused on simplicity, it only has the barnacles that matter most to the discerning bike tourist
Run racks and panniers, framebags, or all of the above
Disc brake-specific, single position vertical rear dropout makes it less intimidating than other bikes in the category
Clearance for 700 x 47mm tires (with or without fenders), 27.5 x 2.8” tires (27.5 x 2.6” with fenders), and 26 x 3” tires (26 x 2.8” with fenders)
Geometry:
SIZE | XS | SM | MD | LG | XL |
---|---|---|---|---|---|
Reach | 376 | 397 | 419 | 434.5 | 444 |
Stack | 553 | 567 | 576 | 590 | 609 |
Head Tube Angle | 70.0° | 71.0° | 71.0° | 71.0° | 71.0° |
Head Tube Length | 110 | 120 | 130 | 145 | 165 |
Seat Tube Length | 335.6 | 406.4 | 457.2 | 508 | 558.8 |
BB Drop | 60 | 60 | 60 | 60 | 60 |
Wheelbase | 1032 | 1047.5 | 1073 | 1093 | 1109 |
Chainstay Length | 435 | 435 | 435 | 435 | 435 |
Top Tube Length, Actual | 534 | 547.5 | 570 | 591.5 | 610.3 |
Top Tube Length, Effective | 545 | 570 | 595 | 615 | 630 |
Seat Tube Angle | 73.0° | 73.0° | 73.0° | 73.0° | 73.0° |
Standover Height | 709 | 750.5 | 780 | 812 | 845.5 |
Stem Length | 80 | 80 | 90 | 90 | 100 |
Stem Angle | 6° | 6° | 6° | 6° | 6° |
Crank Length | 170 | 170 | 175 | 175 | 175 |
Fork Length | 420 | 420 | 420 | 420 | 420 |
Fork Rake | 43 | 43 | 43 | 43 | 43 |
